JBL Club A5055 5-Kanaals Versterker (4x 45W + 1x 500W)

JBL Club A5055 5-Kanaals Versterker (4x 45W + 1x 500W)

5-kanaals
versterker

Waardevolle autoversterker met JBL-vermogen en prestaties.
De Club A5055 5-kanaalsversterker levert een krachtige 50 watt RMS naar elk van de voor- en achterluidsprekers in uw auto, en maar liefst 500 Watt RMS naar het subwooferkanaal - een veel slimmere verhouding tussen subwoofer en volledig bereik dan wat typisch is bij 5-kanaals versterkers. U kunt de versterker ook overbruggen naar de 3-kanaalsmodus om 140 watt RMS aan uw voorluidsprekers te leveren terwijl u uw sub aanstuurt met 500 watt RMS. Dankzij de ingangen op luidsprekerniveau kan deze versterker in bijna elk systeem worden geïntegreerd, zelfs een systeem dat gebruikmaakt van de fabrieksradio van uw auto. Afzonderlijke high-pass en low-pass cross-overs op de voor- en achterkanalen zorgen ervoor dat u de perfecte roll-off kunt kiezen die het beste past bij de plaatsing van de luidsprekers en de akoestiek in de cabine. Het subwooferkanaal beschikt over een low-pass crossover, selecteerbare basversterking en faseschakelaar om de prestaties van de subwoofer te optimaliseren.

Kenmerken
Compact formaat
Hoog en laag ingangsniveau
Variabele crossover en basversterking
Laag geluidsniveau en vervorming
Ingangsniveauregeling
Volledige ingebouwde bescherming
Faseschakelaar
RBC bedrade afstandsbediening

Klasse AB + D-versterkertechnologie
Inschakelmodus

Features and Benefits
Compact size
The JBL Club A5055 amplifier features a low-profile chassis and a small overall footprint to fit in more vehicles where available space is limited.
High and low level input
Speaker-level and low-level inputs allow the Club A5055 to integrate with both aftermarket and factory car stereo systems.
Variable crossover and bass boost
Unlike many amplifiers available at similar prices, the JBL Club A5055 features variable electronic crossovers and bass boost circuits allowing for precise system tuning and performance.
Low noise and distortion
The Club A5055 has been engineered using Balanced Differential Inputs to ensure low noise and distortion even at high output levels. This also makes it far less susceptible to line induced radiated engine noise.
Input Level Control
When the low-level inputs are used, this control adjusts the input sensitivity between 200mVrms and 2.0 Vrms. When high-level inputs are used, this control adjusts the input sensitivity between 2Vrms and 20Vrms.
Full on-board protection
On-board circuitry protects the Club A5055 from shorts, high-temperature, overvoltage and undervoltage. An LED indicator is provided to let you know when one of these conditions exists.
Phase Switch
This switch changes the input phase to inverted or non-inverted. This is especially helpful with the subwoofer channel.
RBC wired remote
The RBC wired remote is an easy installation and can be mounted for convenient volume adjustment from driver’s seat.
Class AB+D amp technology
The JBL Club A5055 5 channels subwoofer amplifier delivers 780-Watts RMS using a
Class AB+D amplifier design to ensure high output and minimum current draw.
Turn-on mode
This switch changes DC to REM to adapt with low-level signals or high-level signals, this is especially helpful as part of remote turn-on lead of your installation more choice. A selectable “Turn-on mode” can protect battery to avoid current drain, when you don’t expect turn on your amplifier.

Technical specifications:
5 channel car amplifier
50 watts RMS x 4 + 320 watts RMS x 1 at
4 ohms
65 watts RMS x 4 + 500 watts RMS x 1 at
2 ohms
140 watts RMS x 2 bridged at 4 ohms +
500 watts RMS x 1 at 2 ohms
Variable high- and low-pass filters (32–320Hz,
12dB/octave) on front and rear channels
Low-pass filter (32–320Hz, 12dB/octave) on subwoofer channel
Bass boost on subwoofer channel
(0-12dB at 45Hz)
Phase switch on subwoofer channel
(0, 180 degrees)
Preamp and speaker-level inputs
Fuse rating: 30A x 3
4-gauge power and ground leads recommended — wiring and hardware not included with amplifier
W x H x D = 360mm x 51.3mm x 180mm
W x H x D = 14-3/16'' x 2-1/16'' x 7-1/8''

Verpakkingsinhoud
One Club A5055 five channel amplifier
4 Bare wire-to-RCA adapters
Six 30A ATO fuses (3 installed, 3 spare)
Remote bass control module
16.5’ Remote control cable (RJ-25 plugs on both ends)
2 Self-tapping screws for remote (M3 x 15mm)
4 Mounting screws (M4 x 53mm)
Owner’s Manual
Two JBL stickers
1 logo badage
